OpenISAC

About OpenISAC

Integrated sensing and communication (ISAC) is envisioned to be one of the key technologies in 6G. OpenISAC is a versatile and high-performance open-source platform designed to bridge the gap between theory and practice.

Built entirely on open-source software (UHD + C++ + Python), it supports real-time OFDM-based sensing and communication. A key feature is its novel over-the-air synchronization mechanism, enabling robust bistatic operations without wired connections.

If you find this repository useful, please cite our paper:

Z. Zhou, C. Zhang, X. Xu, and Y. Zeng, "OpenISAC: An Open-Source Real-Time Experimentation Platform for OFDM-ISAC with Over-the-Air Synchronization," submitted to IEEE Trans. Wireless Commun., Jan. 2025.

Affiliation

Yong Zeng Group at the National Mobile Communications Research Laboratory, Southeast University and the Purple Mountain Laboratories

Community

• Join our QQ Group
• Bilibili Channel (Yong Zeng Group)

WeChat Official Account:

What it is — and what it is not

What OpenISAC is

OpenISAC is a simple OFDM-based communication and sensing system designed for academic experiments and rapid algorithm validation. Its goal is to provide a clean, minimal, easy-to-modify OFDM platform so researchers can iterate quickly on PHY/sensing ideas without the overhead of a full standard-compliant stack.

Because it focuses on simplicity, OpenISAC typically requires less compute and can often run at higher sampling rates than more complex, feature-complete systems.

What OpenISAC is not

OpenISAC is not intended to be a standard-compliant implementation. It does not aim to comply with existing standards such as Wi-Fi or 5G NR.

It is also not meant to replace or compete with full-stack open-source standard implementations such as openwifi or OpenAirInterface. If your goal is interoperability, standards compliance, or a production-grade protocol stack, those projects are the right direction.

When to use it

• Prototyping and testing new OFDM/ISAC algorithms
• Fast “idea → experiment” cycles with a minimal PHY
• Research setups where interoperability is not required

When not to use it

• Building a Wi-Fi/NR-compatible system
• Needing real-world standard features (full MAC/stack behavior, interoperability, certification-oriented behavior, etc.)

Sensing Demo

Communication Demo

Hardware Requirements

Backend (C++)

To set up the complete system, you will need:

• USRP Devices: 2 units (e.g., USRP X310, B210)
• Computers: 2 units (High performance recommended)
• Antennas: 3 total
• OCXO: 2 units (Required for both USRPs)

Connection Setup

BS Node: 1x Computer, 1x USRP (2 Antennas: 1 TX, 1 RX), OCXO.

UE Node: 1x Computer, 1x USRP (1 Antenna: RX), OCXO.

Interface

• >= 10 Gigabit Ethernet (10GbE) for X-series
• USB 3.0 for B-series

Frontend (Python)

• Computer: 1x Computer (Windows or Linux). Can be one of the backend computers or a separate machine.
• CPU: High performance CPU (i7 10700 or better) if no GPU is available.
• GPU: A Nvidia GPU is recommended for acceleration.

Software Requirements

Backend (C++)

Operating System

Ubuntu 24.04 LTS

Dependencies & Installation

1. DPDK (Optional)

sudo apt update
sudo apt upgrade
sudo apt install dpdk dpdk-dev

Note: Install DPDK before building UHD if you plan to use it.

2. UHD (USRP Hardware Driver)

Follow the official Ettus guide. Tested on UHD v4.9.0.1.

3. Install Aff3ct

sudo apt-get install nlohmann-json3-dev
git clone https://github.com/aff3ct/aff3ct.git
cd aff3ct
git submodule update --init --recursive
mkdir build
cd build
cmake .. -G"Unix Makefiles" -DCMAKE_CXX_COMPILER="g++" -DCMAKE_BUILD_TYPE="Release" \
-DCMAKE_CXX_FLAGS="-funroll-loops -march=native" -DAFF3CT_COMPILE_EXE="OFF" \
-DAFF3CT_COMPILE_SHARED_LIB="ON" -DSPU_STACKTRACE="OFF" -DSPU_STACKTRACE_SEGFAULT="OFF" \
-DCMAKE_CXX_FLAGS="${CMAKE_CXX_FLAGS} -faligned-new"
make -j$(nproc)
sudo make install

4. Clone & Build OpenISAC

cd ~
git clone https://github.com/zhouzhiwen2000/OpenISAC.git
cd OpenISAC
mkdir build
cd build
cmake ..
make -j$(nproc)

5. Performance Tuning

cd ~/OpenISAC
chmod +x set_performance.bash
./set_performance.bash

Note: secure_boot needs to be turned off in your BIOS settings to enable RT_RUNTIME_SHARE functionality.

UHD Thread Priority Configuration

If you see [WARNING] [UHD] Failed to set desired affinity for thread, you need to enable real-time priority for your user.

sudo groupadd usrp
sudo usermod -aG usrp $USER

Then add the following line to /etc/security/limits.conf:

@usrp - rtprio 99

Log out and back in for changes to take effect.

6. CPU Isolation and Execution

To ensure stable real-time performance, isolate CPU cores for signal processing.

Step 1: Isolate System Cores

cd ~/OpenISAC
chmod +x isolate_cpus.bash
sudo ./isolate_cpus.bash

Step 2: Run Application on Isolated Cores

Use the script to launch your application on the isolated cores:

cd build
sudo ../isolate_cpus.bash run ./OFDMModulator

Note: Always use the wrapper script when CPU isolation is active.

Reset Configuration (Optional)

To restore the system to its default state (allowing all processes to use all cores):

sudo ./isolate_cpus.bash reset

Frontend (Python)

It is recommended to use a conda or venv environment with Python 3.13.

Install Dependencies

pip install -r requirements.txt

Note: ffmpeg is required for video streaming demonstrations.

• Ubuntu: sudo apt install ffmpeg
• Windows: Download from ffmpeg.org and add to PATH, or place executable in the working directory.

Enable GPU Acceleration (Optional)

If an Nvidia GPU is available, install cupy-cuda12x to enable GPU acceleration:

pip install cupy-cuda12x

Typical Usage Example

1. Startup of the BS

sudo -s
cd build
# For X310:
sudo ../isolate_cpus.bash run ./OFDMModulator --args "addr=192.168.40.2, master_clock_rate=200e6, num_recv_frames=512, num_send_frames=512"

# For B210:
sudo ../isolate_cpus.bash run ./OFDMModulator --args "num_recv_frames=512, num_send_frames=512, send_frame_size=11520, recv_frame_size=11520"

Add --default-ip=<your front end IP> if you are using a separate computer for the frontend.

2. Startup of the UE

sudo -s
cd build
# For X310:
sudo ../isolate_cpus.bash run ./OFDMDemodulator --args "addr=192.168.40.2, master_clock_rate=200e6, num_recv_frames=512, num_send_frames=512"

# For B210:
sudo ../isolate_cpus.bash run ./OFDMDemodulator --args "num_recv_frames=512, num_send_frames=512, send_frame_size=11520, recv_frame_size=11520"

Add --default-ip=<your front end IP> if you are using a separate computer for the frontend.

3. Stream video to the BS

ffmpeg -re -stream_loop -1 -fflags +genpts -i video.mp4 -an -c:v libx264 -x264-params keyint=5:min-keyint=1 -b:v 3000k -minrate 3000k -maxrate 3000k -bufsize 1M -f rtp -sdp_file video.sdp "rtp://<your IP of the BS>:50000"

If you are streaming locally, your IP of the BS can be set to 127.0.0.1.

4. Play video from the UE

Copy video.sdp to the video receiver, modify m=video 50000 RTP/AVP 96 to m=video 50001 RTP/AVP 96.

ffplay -protocol_whitelist file,rtp,udp -i video1.sdp

Note that this command should be run on the frontend.

5. Run monostatic frontend

python3 .\plot_sensing_microDoppler_CPP_MTI.py

6. Run bistatic frontend

python3 .\plot_bi_sensing_microDoppler_CPP_MTI.py

Arguments Table

OFDM Modulator

The OFDMModulator (BS Node) can be configured using the following command-line arguments:

OFDM Demodulator

The OFDMDemodulator (UE Node) supports the following arguments:
